Products

Matches Bend Contact Box Series

OEM service: 1、Color: support red ,brown or other customsized 2、Insert: support brass,steel or other 3、Model: support OEM model
Model:
WB-35Q 122
Voltage:
35KV
Height:
412
Diameter:
557
Screw:
2-M10
Material:
Epoxy resin
MOQ:
2 pcs
Certificate:
CE,RoHS,SGS,REACH
Matches Bend Contact Box Series



Insulation Contact Box Description

The contact box product uses epoxy resin material with excellent insulation performance, and is injection molded using the static mixed APG process commonly used in the market. It uses high-quality pressure-resistant, partial discharge and other testing equipment to strictly control the product quality in accordance with national standards.

1. Material: epoxy resin
2. Application: KYN61C-40.5KV Indoor HV switchgear fittings
3. Certificate: CE
4. Reliable installation, achieve five preventation requirement.
5. More than 10 years experience for manufacturing in this line
6. Most competitive prices with best quality, promptly delivery



Application

Epoxy resin cast insulation contact box, connect with charged display device, used in switchgear application.
The contact box is an epoxy resin APG process pressure gel molding structure used in various handcart switch cabinets, which plays a role in insulation isolation and excessive connection.



Our service

Delivery

By express/By sea/By air/By land transportation

Supply

5000pcs/week

Sample

The seller provides 2 samples for free, and the buyer pays the freight

Packing

By carton
